Sanlorenzo Sd112 (2018)

Notas de la instrumentación

Wheelhouse Steering Position:
Radar (Black Box type)
Chart Plotter (Black Box type)
Control keyboard for Radar and Chart Plotter
3 x 19” Monitors interfaced with radar, chart plotter, on-board computer and CCTV
Rudder angle indicator
Autopilot control panel with dedicated tiller
2 x Multi-function instruments (with Anemometer data repetition)
1 x VHF
1 x Magnetic Compass
1 x Search light control panel
Sundeck Manoeuvring Position:
1 x Rudder Angle Indicator
Antennae Mast:
1 x VHF Antenna
2 x GPS Antennas
Open Array 6’ Radar Antenna
Anemometer
Searchlight
Intercom:
Dedicated communication system to connect the wheelhouse steering positions with the engine room
Internal Communication Telephones:
Main saloon
Owner’s cabin
Crew dinette
Captain’s cabin
VIP cabins
Guest cabins
Wheelhouse
Sky lounge
ENTERTAINMENT EQUIPMENT
Saloon Main Deck:
TV ‘Smart TV’ LED 50” with an up/down mechanism
Multi zone amplifier with AIR play and 5.1 home theatre kit comprising a subwoofer and 5 ceiling
integrated speakers with connection to the cockpit and sundeck
DVD Blu-ray 3D player
iPad Mini for central control of equipment and docking station
Cockpit Main Deck:
2 x Paired speakers integrated in the headlining connected to the saloon equipment
Controlled by the saloon iPad Mini
Sky Lounge Upper Deck:
TV ‘Smart TV’ LED 46” with an up/down mechanism
Multi zone amplifier with AIR play and 5.1 home theatre kit comprising a subwoofer and 5 ceiling
integrated speakers with connection to the cockpit and sundeck
DVD Blu-ray 3D player
iPad Mini for central control of equipment and docking station
Cockpit Upper Deck:
2 x Paired speakers integrated in the headlining connected to the sky lounge equipment
Controlled by the sky lounge iPad Mini
Sun Deck:
4 x (2 + 2) Paired speakers integrated in walls connected to the sky lounge equipment
iPad Mini for central control of the equipment and docking station
Owner’s Cabin:
TV ‘Smart TV’ LED 40”
Amplifier with AIR play and 2.1 home theatre kit comprising a subwoofer and 2 ceiling integrated
speakers
DVD Blu-ray 3D player
iPad Mini for central control of equipment and docking station
Forward Guest Cabins (2):
TV ‘Smart TV’ LED 28”
Amplifier with 2 ceiling integrated speakers
DVD Blu-ray 3D player
Infrared signal repeater
Aft Guest Cabins (2):
TV ‘Smart TV’ LED 32”
Amplifier with 2 ceiling integrated speakers
DVD Blu-ray 3D player
Infrared signal repeater
Captain’s Cabin: 8
Autoradio with DVD player and 2 ceiling integrated speakers
TV predisposition
Crew Cabins:
Predisposition for TV, car stereo and ceiling speakers
Galley/Crew Dinette:
TV LED 28”
Compact Hi-Fi system with 2 ceiling integrated speakers
DVD player connected to the Hi-Fi system
Infrared signal repeater
Helm:
Autoradio with 2 ceiling integrated speakers
Bow Area:
Predisposition for speakers connected to the sun deck zone of the sky lounge amplifier
Land TV antenna and AM/FM radio antenna
Audio system managed by CRESTRON

Notas de armamento

Bow Thruster: Electrical bow thruster 400VAC/50Hz 3-phase, 45kW
Stabilizers: 2 x CMC Electric zero speed stabilizers 400 VAC/50Hz 3-phase, 5kW
Trimming System: Stainless-steel Intruder (AISI 316) on the transom, below the waterline, to raise the stern
during navigation and increasing the performances
Air Conditioning: 240,000 BTU/h Chiller Unit composed by 2 x compressors installed in the engine room
ELECTRICAL SYSTEM
Electrical Circuits:
400VAC/50Hz 3-phase grounded neutral, for main power circuits
230VAC/50Hz single phase for accommodation and technical area lights
24 VDC from batteries, with negative to earth, for small appliances, visual signals, night accommodation
lights, emergency lights, electronics and main engine starters
12VDC from batteries with grounded neutral, for diesel generators start up and VHF emergency power supply
12VDC from transformer DC/DC for radio navigation system

Generators:
1 x 70 kW KOHLER 70EFOZDJ, and 1 x 54 kW KOHLER 54EFOZDJ 400/230 VAC, 50Hz 3-phase @ 1500 RPM

Batteries:
Services Batteries: 24VDC gel/AGM batteries (500Ah)
Main Engines Electronic Control Batteries: 24VDC gel/AGM battery for each of main engines’ own electronic control
Main Engines Start Batteries: 24VDC gel/AGM battery for main engines’ start up
Generators Start Batteries: 12VDC gel/AGM batteries for starting each electric generator
Emergency Batteries: 24VDC gel/AGM batteries for stairs, escape hatches and passages emergency lights; engine room emergency lights; emergency power supply for navigation lights and relevant
switchboard; emergency power supply for fire detection system; emergency power supply for navigation
electronics; emergency power supply for firefighting pump
VHF Emergency Battery: 12VDC gel/AGM battery
Battery Chargers:
1 x 24VDC automatic battery charger for service batteries
1 x 24VDC automatic battery charger for main engines start up batteries
1 x 24VDC automatic battery charger for main engines electronic control batteries
1 x 24VDC automatic battery charger for emergency batteries
1 x 12VDC automatic battery charger for generators start up batteries
1 x 12VDC automatic battery charger for the VHF emergency batteries
Shore Power: GLENDINNING Cablemaster CM8 for shore sockets 100/125 A with 20m cable
Insulation Transformer: 400VAC/50Hz 3-phase, 60kVA 3ph/3ph+G+N
